| Product Number |
|
| Type |
| Scale |
1/10th |
| Brushed/Brushless |
Brushless |
| Sensored/Sensorless |
Sensored |
| Waterproof |
NO |
|
| Specifications |
| Cont./Peak Current |
60A/200A |
| Input Voltage |
2S Lipo |
| BEC BEC Output |
Switch Mode 6V/7.4V @4A |
|
| Wires & Connectors |
| Input Wires |
Black--14AWG-175mm*1 Red--14AWG-175mm*1
|
| Output Wires |
Blue-14AWG-175mm*1、Yellow-14AWG-175mm*1、Orange-14AWG-175mm*1 |
| Input Connectors |
No |
| Output Connectors |
No |
|
| ESC Programing via |
| SET Button on ESC |
Supported |
| LED Program Box |
Supported |
| LCD G2 Program Box |
Supported |
| LCD PRO |
Supported(Bluetooth not supported) |
| OTA Programmer |
Not Supported |
| Program Port |
Shared with fan port |
|
| Data Recording |
| Extreme value |
Not Supported |
| Real-time Data |
Not Supported |
| Historical data (Graph) |
Not Supported |
|
| Firmware |
| Firmware Upgrade |
Not Supported |
|
| Size & Weight |
| Size |
35.0*31*30.8mm |
| Weight |
66.5g (Included wires&connectors) |
|
| Applications |
| Motors |
Sensored/Sensorless Brushless motor |
| Vehicles |
1/10th Touring, Buggy, Drift,1/12th and 1/14th Vehicles |
| Applicable Motor |
QUICRUN 3650 SD G2 |
|
